CAB E4 labelprinter

Product code : BYPOS-3068


Elementi prodotti raggruppati
Nome prodotto Prezzo Azioni
Nessuna opzione di questo prodotto è disponibile.

De CAB E4 printer wordt geleverd met een gratis PC label design software. Dit laat u toe om professionele etiketten te ontwerpen en te printen met zowel tekst, afbeeldingen, barcodes, datum- en tijdvelden, vaste- en variabele velden, database connectie, enz.
Dankzij een Windows 2000, 2003, XP driver kan u deze printer ook onmiddellijk aansturen vanuit elk Windows programma zoals, Word, Excel, enz.

Een compacte Label printer, die vooral gebruikt wordt voor kleinere en medium opdrachten. Een voordeel is dat de E4 printer rollen tot 152 mm diameter en standaard transfertlint tot 360 m kan gebruiken. Er wordt standaard de gratis label design sofware "e-label" bijgeleverd.

Label printere4
Printhead
Printing method Thermal / Thermal transfer
Print resolution dpi 200 300
Print speed up to mm/s 100 75
Print width up to mm 108 106
Material
Labels, continuous rolls or fan-folded Standard thermal paper, cardboard, plastics
PET, PE, PP, PVC, PU, Acrylat, PI
Material thickness mm 0,08 – 0,20
Label width1) mm 25 – 106
Width of liner or continuous material mm 25 – 110
Label height1) from mm 10
Label height1) up to mm 8000 4000
Media roll: Total diameter up to mm 152
Media roll: Core diameter mm 25 / 75
Media roll: Winding direction outside

Ribbon

Ink: inside

Roll diameter up to 76 mm

Core diameter 25 mm

Running length variable up to 360 m

Width up to 110 mm

Dimensions

Height x depth x width: 200 x 329 x 256 mm

Weight: 3,5 kg

Label sensor

Reflective sensor from the bottom – for label edge, punching or print marks from the center 15 mm to the left or 30 mm to the right

Electronics

Processor clock rate: 50 MHz

RAM: 16 MB

ROM: 2 MB Flash

Operation panel

Buttons: Pause, Feed, Cancel

3 LED display

Interfaces

Parallel Centronics
USB
Serial RS 232 C
Ethernet 10/100 Base



Manufacturer CAB
